Command reference
R&S
®
ZNB/ZNBT
1258User Manual 1173.9163.02 ─ 62
[SENSe<Ch>:]CORRection:LOSS<PhyPt>:FREQuency <RefFreq>
[SENSe<Ch>:]CORRection:LOSS<PhyPt>:SECond:FREQuency <RefFreq>
These commands define the reference frequencies f
1
and f
2
for the offset loss approxi-
mation.
The corresponding losses can be defined using [SENSe<Ch>:]CORRection:
LOSS<PhyPt>:OFFSet.
Suffix:
<Ch>
.
Channel number
<PhyPt> Physical port number
Parameters:
<RefFreq> Reference frequency
Range: Frequency range of the analyzer model.
Increment: 1 MHz
*RST: 1000000000 Hz (= 1 GHz)
Default unit: Hz
Manual operation: See "Loss at DC / Loss at 1st Freq / 1st Freq for Loss / Use 2nd
Freq / Loss at 2nd Freq / 2nd Freq for Loss" on page 607
[SENSe<Ch>:]CORRection:LOSS<PhyPt>:OFFSet <OffsetLoss>
Defines the frequency-independent part (DC value) of the offset loss.
Suffix:
<Ch>
.
Channel number of the offset-corrected channel
<PhyPt> Port number of the analyzer
Parameters:
<OffsetLoss> Frequency-independent part of the offset loss
Range: -200 dB to +200 dB
Increment: 0.001 dB
*RST: 0 dB
Default unit: dB
Example: See [SENSe<Ch>:]CORRection:EDELay<PhyPt>:ELENgth
Manual operation: See "Loss at DC / Loss at 1st Freq / 1st Freq for Loss / Use 2nd
Freq / Loss at 2nd Freq / 2nd Freq for Loss" on page 607
[SENSe<Ch>:]CORRection:LOSS<PhyPt>:SECond:STATe <Boolean>
Defines whether the second reference frequency f
2
is used for the offset loss approxi-
mation.
The second reference frequency and its associated loss value can be defined using
[SENSe<Ch>:]CORRection:LOSS<PhyPt>:SECond:FREQuency and
[SENSe<Ch>:]CORRection:LOSS<PhyPt>:SECond.
