Epson AcuLaser CX11 Service Manual

EPSON AcuLaser CX11/CX11F Revision B
OPERATING PRINCIPLES Printer Section Operating Principle 108
2.2.5 Xerographic
This section explains and illustrates the main functional components that consist of the
Xerographic.
 The Xerographic is divided into the following four blocks based on the basic
configuration.
 ROS ASSY
 Photoconductor Unit
 Development
 2nd BTR
 FUSER ASSY
Figure 2-44. Xerographic Structure
ROS ASSY
Development
Leg_06_003RA
2nd BTR
