EPSON AcuLaser CX11/CX11F Revision B
OPERATING PRINCIPLES Overview 83
Fuser unit New part detection Not available --- Enter Reset from the control panel.
Unit detection Available Electrical continuity ---
Life detection Near-end detection Available Software counter ---
End detection Available Software counter ---
Developer unit New part detection Not available --- Enter Reset from the control panel.
Unit detection
Not available
--- When not installed, “Install xxxx TnrCart” is displayed on the
panel.
Color detection
Available
Recognized by rib Cannot be incorrectly installed as the location of the holes are
different for each color.
Life detection Near-end detection Available Software counter ---
End detection Available Software counter ---
Secondary transfer unit New part detection Not available --- Reset from the Control Panel.
Unit detection Not available --- ---
Life detection Near-end detection Available Software counter Not displayed on the panel as it is supposed to be replaced at the
same time as the Fuser unit.
End detection Available Software counter
Table 2-3. Sensor (Scanner/ADF)
Unit Detection Item Availability Detection Method Remarks
Scanner unit Opening/Closing of the DOC/
ADF covers
Available
Magnet sensor Connected directly to the controller with a cableDetection part on
the upper housing
Magnet on the cover side
CR home sensor Available Photosensor CR home position detection
ADF unit ADF document presence
detection
Available
Photosensor+Actuator Make sure to insert papers to the correct position
B5/LT detection
Available
Micro SW Sets to A4 if not detected properly
Detects by the operation of the side guideSW on the backside of
the tray
AS sensor
Available
Photosensor+Actuator Detects paper presence between the place where documents are
picked up and the separation roller
RS sensor Available Photosensor+Actuator Detects paper presence on the turning roller
Opening/Closing of the ADF
cover
Available
Micro SW Cover sensor to be opened for clearing paper jam
No interlock function
Table 2-2. Sensor (printer section)
Unit Detection Item Availability Detection Method Remarks
