EPSON AcuLaser CX11/CX11F Revision B
APPENDIX Parts List 588
7.4 Parts List
7.4.1 Printer Section
MAIN UNIT
Table 7-5. Main Unit
Diagram No. Part Name
01-01-02 TRAY EXTENSION
01-01-03 COVER TOP
01-01-04 COVER HUSER
01-01-05 COVER TOP SIDE L
01-01-06 COVER TOP SIDE R
01-01-07 SWITCH ASSY TOP
01-01-10 COVER CLEANER
01-01-100 “LOGO PLATE,13X54;C”
01-01-12 FOOT REAR
01-01-13 FOOT FRONT
01-01-14 COVER MSI
01-01-15 COVER FRONT-L
01-01-16 COVER FRONT ASSY-U
01-01-17 “CONTROL,PANEL”
01-01-18 HARNESS
01-01-19 COVER ASSY LH
01-01-20 COVER LH
01-01-21 COVER ESS
01-01-22 SWITCH ASSY FUSER
01-01-23 COVER TRAY
01-01-24 COVER INNER TOP
01-01-26 EXIT CHUTE SWITCH
01-01-27 SWITCH INLK FRONT
01-01-28 COVER ASSY RH
01-01-32 COVER DUP
01-01-33 COVER INNER L
01-01-34 SWITCH INLK FRONT
01-01-36 EXIT CHUTE SWITCH
01-01-99 KIT SLIDE BAR
12-02-01 PWBA MCU
12-02-02 FFC-ASSY LV/MCU
12-02-03 LV/HVPS
12-02-04 HARNESS ASSY AC
12-02-05 FFC-ASSY ESS
12-02-07 “BOARD ASSY., MAIN”
12-02-08 “BOARD ASSY.,MEMORY”
12-02-10 HARNESS ASSY MAIN
12-02-12 PWBA FUSER CONT
12-02-13 POWER CABLE
12-02-13 POWER CABLE
04-01-01 MSI ASSY
04-01-02 ROLL ASSY MSI
04-01-08 ROLL MSI
04-01-09 CHUTE MSI
04-01-11 GEAR MANUAL
04-01-12 GUIDE SIDE L
04-01-13 GUIDE ASSY SIDE R
04-01-15 PLATE BOTTOM ASSY MSI
04-01-16 HOLDER ASSY RETARD MSI
04-01-17 PLATE ASSY RETARD
04-01-20 OIL DAMPER
Table 7-5. Main Unit
Diagram No. Part Name
