EPSON AcuLaser CX11/CX11F Revision B
TROUBLESHOOTING Printer 257
FIP-P3 Solid Black Print
Before starting troubleshooting, inspect the feed path of the printer paper. Check the
paper feed path for metal staples, paper clips, paper scraps, and other foreign matter.
 Problems
Completely black pages are printed.
 ESS and possible parts that caused the error
 ROS ASSY
 Photoconductor Unit
 HOUSING ASSY-GUIDE AD
 2ND BTR ASSY
 PWBA MCU
 LV/HVPS
 500 FEEDER ASSY OPTION
Step Check Yes No
1
Check connection of ROS ASSY connector
Is the connector firmly connected to ROS
ASSY?
Go to Step [2]. Connect the
connector.
2
Check of contact between Photoconductor
Unit and frame
Are the contacts of Photoconductor Unit and
HOUSING ASSY-GUIDE AD dirty or
deformed?
Clean or replace
relevant parts.
Go to Step [3].
3
Cover the entire window of ROS ASSY and
execute a test print.
Is the print completely black?
Replace LV/
HVPS. (p.435)
Go to Step [4].
4
Cover half of the window of ROS ASSY and
execute a test print.
Is the print, half white and half black?
Go to Step [5]. Replace PWBA
MCU. (p.432)
5
Check after replacement of ROS ASSY
Replace ROS ASSY. (p.401)
Make a test print of the problem image.
Is the image printed normally?
End of procedure Replace “ESS and
possible parts that
caused the error”.
