EPSON AcuLaser CX11/CX11F Revision B
APPENDIX Fax Unit System 660
SERVICE CALL ERROR
Table 7-22. Service Call Error
External
Error Code
Internal
Code
Description Cause Remedies
Panel
Display
(reference)
Report Display Trigger for Stopping Operation
Notification
Message
MAIN SUB
100 000 0x1000
An error occurs in reading and writing SDRAM
during power-on sequence
SDRAM failure Replace the fax board
*1, *2
External error code 34H: Something is wrong with devices
required for a fax communication
End of initialization
100 001 0x1001
The product failed to write date information in RTC
Not used --- --- --- --- ---
100 002 0x1002
The product failed to read time after initializing the
clock
Not used --- --- --- --- ---
100 003 0x1003
The product failed to write into the fax flash
memory
Flash memory failure Replace the fax board
*1, *2
External error code 34H: Something is wrong with devices
required for a fax communication
---
100 004 0x1004
SUM check of the fax flash memory was not
performed correctly
Flash memory failure Replace the fax board
*1, *2
External error code 34H: Something is wrong with devices
required for a fax communication
End of initialization
Diagnosing job
termination
100 005 0x1005
An error occurs in reading and writing SRAM
during power-on sequence
Not used --- --- --- --- ---
100 006 0x1006
SRAM backup failure Not used --- --- --- --- ---
100 007 0x1007
Normal writing on the EEPROM was not
performed
Not used --- --- --- --- ---
100 008 0x1008
Fault of parts in the PWBA CONT
(An error of writing/reading image data on the
memory)
SDRAM failure Replace the fax board
*1, *2
External error code 34H: Something is wrong with devices
required for a fax communication
Diagnosing job
termination
100 009 0x1009
Fault of parts in the PWBA CONT
(BM in the ASIC could not be cleared)
Not used --- --- --- --- ---
100 010 0x100A
Fault of parts in the PWBA CONT
(MN86064 related error)
Not used --- --- --- --- ---
100 011 0x100B
Fault of parts in the PWBA CONT
(ASIC related error)
ASIC failure Replace the fax board
*1, *2
External error code 34H: Something is wrong with devices
required for a fax communication
Diagnosing job
termination
100 012 0x100C
The ASIC could not clear buffer memory Not used --- --- --- --- ---
100 013 0x100D
The product failed to write into the modem flash
memory
Not used --- --- --- --- ---
100 014 0x100E
Modem failure Modem failure Replace the fax board
*1, *2
External error code 34H: Something is wrong with devices
required for a fax communication
Diagnosing job
termination
100 900
--- This code is used by the MFP
(Using for fax is prohibited)
--- --- --- --- --- ---
