EPSON AcuLaser CX11/CX11F Revision B
TROUBLESHOOTING Printer 204
FIP-37
 Panel Message
 Service Req E514
 Possible parts that caused the error
 Troubleshooting
 FFC-ASSY ESS  PWBA MCU
 PWBA ESS
Step Check Yes No
1
Check of connection of FFC-ASSY ESS
Re-connect FFC-ASSY ESS of PWBA ESS to
PWBA MCU. Does the error recur when a test
print is made?
Go to Step [2]. End of procedure
2
Check of connection of FFC-ASSY ESS
Is FFC-ASSY ESS damaged or broken?
Replace FFC-
ASSY ESS.
(p.437)
Go to Step [3].
3
Check after replacement of PWBA MCU
Replace PWBA MCU. (p.432)
Does the error recur when a test print is made?
Replace PWBA
ESS. (p.437)
End of procedure
