EPSON AcuLaser CX11/CX11F Revision B
TROUBLESHOOTING Printer 282
FIP-N2 At Standby
 Possible parts that caused the error
 Troubleshooting
îš„ MOT ASY FSR îš„ FUSER ASSY
îš„ 2ND BTR ASSY
Step Check Yes No
1
Is abnormal noise being generated from
MOT ASSY FSR?
(It rotates when the temperature of FUSER
ASSY reaches the specified value)
Replace MOT
ASSY FSR.
Go to Step [2].
2
Is abnormal noise being generated by
FUSER ROLL in FUSER ASSY that is
driven by MOT ASSY FSR?
Clean or replace
FUSER ROLL.
Go to Step [3].
3
Is abnormal noise being generated from 2ND
BTR ASSY that is driven by MOT ASSY
FSR?
Clean or replace
2ND BTR
ASSY.
