Epson AcuLaser CX11 Service Manual

EPSON AcuLaser CX11/CX11F Revision B
66
PRINTER RESET ITEMS
SUPPORT FUNCTION ITEM
PRINTER ADJUSTMENT FUNCTION ITEMS
USB I/F SETUP ITEMS
Note *1: After this item is changed, the setting value takes effect after a warm boot or after the
power is turned on again. While it is reflected in the Status Sheet and EJL read-back,
the actual change takes effect after a warm boot or after the power is turned on again.
*2: Displayed only when the D4 support USB external device is connected.Changed to
“USB Config=No” automatically when exitting the setup mode.
*3: Displayed only when the D4 support USB external device is connected, and “USB
external device=Yes”. Content of the setting depends on the USB external device
settings.
*4: The actual valid value is displayed (but cannot be changed) when “Get IPAddress =
Auto”.
*5: When the “IP Adress” - “Panel” or “PING” is changed to “Auto”, the setting value of
the “Panel” or “PING” is memorized and it is restored and displayed on the panel
when the setting is changed back to “Panel” or “PING”. The printer displays
“192.168.192.168” if the settings are not made from the panel.
Setup menu Remarks
Clear warning ---
Clear all warning ---
Reset ---
Restart Unit Reboot
Factory Settings ---
Change Toner C ---
Change Toner M ---
Change Toner Y ---
Change Toner K ---
Reset Fuser Counter Overseas destinations only
Setup menu Setup items Remarks
LCD Backlight Auto, On, Off ---
Setup menu Setup items Remarks
Normal 0 - 5 - 15 ---
SemiThk 0 - 5 - 15 ---
Thick 0 - 5 - 15 ---
ExtraThk 0 - 5 - 15 ---
Card 0 - 5 - 15 ---
Envelope 0 - 5 - 15 ---
Feed offset -3.5 - 0.0 - 3.5 mm (mm) The printer reboots.
Scan offset -3.5 - 0.0 - 3.5 mm (mm) The printer reboots.
Calibration --- ---
Setup menu Remarks
USB I/F
*1
Yes, No
USB speed
*1
HS, FS
USB Extl/FConfg
*2
Yes, No
Get IPAddress
*3
Panel, Auto, Ping
IP
*3, 4, 5
0.0.0.0 - 255.255.255.255
SM
*3
0.0.0.0 - 255.255.255.255
GW
*3
0.0.0.0 - 255.255.255.255
NetWare
*3
On, Off
AppleTalk
*3
On, Off
MS Network
*3
On, Off
Rendezvous
*3
On, Off
USB Extl/F Init
*3
---
