EPSON AcuLaser CX11/CX11F Revision B
TROUBLESHOOTING Fax Function 297
PROTOCOL MONITOR LIST
Changing a certain system parameter setting is required to print the Protocol Monitor
List.
When a fax transmitting/receiving job is performed with the list printing enabled,
control protocols (ITU-T.30 protocols) used for the jobs are monitored and printed out
for every job.Verifying the protocols (signals, commands) printed on the list enables to
analyze an error occurrence timing and status.
The contents of the list are as follows.
 Common header
 Fax job result information
 Software version
 Trace data
 Lap time
 Transmitted signal names
 Direction (transmitting or receiving)
 Received signal names
 FCF (Facsimile Control Field)
 FIF (Facsimile Information Field)
The [Protocol Monitor List] can be printed out by changing the parameter setting as
follows.
The system parameter: REP_PROTOCOL_OUT
Maintenance code (Main-Sub): 330-001
Setting value: 0 = Not print (default)
1 = Only when an error occurs
2 = Print always
Figure 3-10. Sample of Protocol Monitor List
Protocol Monitor
Date/Time
: 03/05/06 11:33
Personal Number
: 0XXXXXXXXX
Personal Name
: EPSON
Transmission Information
Start Time Destination Station TtlTime Pages Mode Result Comm. Contents
05/03 11:36 0XXXXXXXXX 1’45” 1/1 SG3 0000
Software Version
FAX Ver.0003 (BOOT1)
Ver.0003 (BOOT2)
Ver.0003 (User)
Modem 5K6E6E01
Trace Data
LAPTIME LOCAL REMOTE FCF FIF
00”2 ANSam →
01”0 CSI → 40 30323632383531323136
01:6 DIS → 80 xxxxxxxx
04”8 ← TSI 43 xxxxxxxx
05”1 ← DCS 83 xxxxxxxx
06”4 ← TCF
07”4 CFR → 84 xxxxxxxx
08”4 ← PIN
10”0 ← PPS. NULL BF00
::
::
::
::
::
1’44’59”2 ←DCN
