Epson AcuLaser CX11 - Antenna Assy

EPSON AcuLaser CX11/CX11F Revision B
DISASSEMBLY AND ASSEMBLY Printer 391
4.2.6.4 ANTENNA ASSY
REMOVAL
1. Remove 2ND BTR ASSY. (p374)
2. Remove COVER ASSY LH. (p321)
3. Remove PWBA MCU. (p432)
4. Remove CHASSIS ASSY ESS. (p440)
5. Remove SENSOR TR-0. (p387)
6. Remove GUIDE CRU ASSY D. (p388)
7. Unhook the hook fastening ARM-COUPLING to GUIDE CRU ASSY D, and
remove ARM-COUPLING from the shaft on GUIDE CRU ASSY D together with
SPRING-TORSION ARM.
8. Turn ARM-COUPLING 90°, and remove ARM-COUPLING.
Figure 4-77. Removal of ANTENNA ASSY (1)
Leg_Sec03_079FB
CAUTION
8)-2
8)-1
7)
