Epson AcuLaser CX11 Service Manual

EPSON AcuLaser CX11/CX11F Revision B
OPERATING PRINCIPLES Overview 80
Figure 2-2. C588Block Diagram of the Main Board
Note *1: Base model does not implement CN704.
*2: Fax model does not implement CN705/CN410.
CN701 CN702
CN703
CN405
CN402
CN410
CN407
CN705
CN502
CN704
IC701
IC701
IC401
IC401
JP3
JP1 JP2 JP4
R422
IC101
IC101
IC103
IC103
CN602
CN601
C588MAIN
IC102
IC102
CN300 ROM/RAM DIMM (90pin)
CN201 RAM DIMM A (90pin)
CN202 RAM DIMM B (90pin)
CN501
ADF I/F
*1
(12Pin)
Sensor I/F
*2
(2Pin)
Panel I/F
(30Pin)
CCD_A I/F
(14Pin)
CCD_B I/F
(13Pin)
Motor I/F
(4Pin)
Engine I/F
(16Pin)
Viedo I/F
(2Pin)
PS0S1
Power (24V)
(2Pin)
FAX I/F
*2
(40Pin)
USB I/F
(2Pin)
Power (5V, 3.3V)
(2Pin)
Cobalt I/F
(30Pin)
