1.3.2.4 Scan Mode
BUTTON FUNCTIONS
Note *1: All the modes become inoperative when system error occurred.
*2: If the error that requires user intervention to be cleared has occurred, users cannot switch modes until they cancel the error.
If there is an error concerning device that is diagnosed as device failure at start-up, switching between modes is impossible.
Button name Idling Running Error LED
Copy Moves to copy mode Invalid Unable to move to copy mode.
In copy mode, switch to print mode.
Fax Moves to fax mode Invalid Moves to fax modeIn fax mode, switch to print
mode.
Scan Moves to print mode Invalid Unable to move to scan mode.
In scan mode, switch to print mode.
Setup Moves to setup mode Invalid Moves to setup modeIn setup mode, switch to print
mode.
One touch speed dial A
One touch speed dial B
One touch speed dial C
Moves to fax mode, and dials the registered number. Invalid Does not shift to fax mode and dial
Advanced/Menu button Shifts from scan mode initial screen to advanced scan menu
screen
Invalid Invalid
Reset button 1. Short press: Performs initialization
2. Long press (hold for more than three seconds): Perform
initialization for all the settings
Invalid Invalid
Up/Down Scrolls up/down in the setting items Invalid Invalid
Left/Right Opens subsequent menus or backs to previous menu, or
exits the menu
Selects and changes the setting
Invalid Invalid
Speed dial Invalid Invalid Invalid
Redial Invalid Invalid Invalid
Cancel button Invalid Local PC: Invalid
Network: Cancels scanner job
Invalid
Asterisk/Hash buttons Invalid Invalid Invalid
Ten-key Invalid Invalid Invalid
Start Standard scanning using the document table: Auto select
Other than the above: Start
Invalid Clears the errorFax initialization
