EPSON AcuLaser CX11/CX11F Revision B
71
1.4 Status Sheet
This section describes Status Sheet that enables you to check current setups for printing
and faxing, and operating history.
1.4.1 Printer Section
STATUS SHEET
Status sheet is available in abridged and complete version.
 Full Status Sheet
Printing a full status sheet is made using the printer driver. It is not printed out if
the driver fails to get information on the printer.
 Abridged Status Sheet
An abridged status sheet is printed under the conditions described below.
Displayed characters vary according to the language setting and are printed in
monochrome.
 Selecting “printer information” from the control panel.
 When a full status sheet cannot be printed out using the printer driver.
Example of these status sheets are shown in Figure1-14 (p73) and Figure1-13 (p72).
The following consumables information is also printed on the status sheet.
Note *: 1,500 page capacity cartridge for K toner is included with shipment and is not
available separately.
The last line printed on the status sheet contains the following information.
1. Firmware version in DDYM format that starts with IA.
2. Type of the device of code ROM.
 *: F lash
 Space : Mask
3. 4-digit CMTD (Color Matching Table Data) version that starts with A.
4. Mechanical controller version expressed by 10-digit numbers that start with MC.
(Refer to “6.4.2.1 Engine Status Sheet” (p555))
5. Space
6. USB ID (31PXXXXXXXXXXXXXXX)
7. Latest connection status of the USB communication mode.
 H: HS
 F: FS
 Space : no connection with USB
C A U T I O N
7
Aside from the printer driver for the AcuLaser CX11/CX11F,
EPW!3 (EPSON Printer Window! 3) needs to be installed to print a
full status sheet.
Information on Consumables Model number
Toner cartridge (C) 1,500 page capacity LP CA4ETC4C
4000 page capacity LP CA4ETC5C
Toner cartridge (M) 1,500 page capacity LP CA4ETC4M
4000 page capacity LP CA4ETC5M
Toner cartridge (Y) 1,500 page capacity LP CA4ETC4Y
4000 page capacity LP CA4ETC5Y
Toner cartridge (K) 4000 page capacity LP CA4ETC5K
*
Photoconductor Unit LPCA4KUT3
