EPSON AcuLaser CX11/CX11F Revision B
TROUBLESHOOTING Printer 153
3.4.4.3 Error Code FIP
3.4.4.3.1 Engine related error
FIP-1
 Panel Message
îš„ Install Y TnrCart
 Possible parts that caused the error
 Troubleshooting
îš„ Toner Cartridge Y îš„ HOUSING ASSY-DEVE Y
îš„ ANTENNA CTRG îš„ HARNESS ASSY MAIN
îš„ ANTENNA ASSY-CTRG îš„ PWBA MCU
Step Check Yes No
1
Model check of Toner Cartridge Y
Is a Toner Cartridge Y that complies with the
specifications attached?
Go to Step[2]. Replace with a
Toner Cartridge
Y that complies
with the
specifications.
2
Attachment check of Toner Cartridge Y
Is the Toner Cartridge Y attached correctly?
Go to Step[3]. After re-
attachment
Go to Step[3].
3
Does the error recur even if the power is
turned ON/OFF several times?
Go to Step[4]. End of procedure
4
Attachment check of HOUSING ASSY-
DEVE Y
Is the HOUSING ASSY-DEVE Y attached
correctly?
Go to Step[5]. After re-
attachment
Go to Step[5].
5
Does the error recur even if the power is
turned ON/OFF several times?
Go to Step[6]. End of procedure
6
Check after replacement of Toner Cartridge Y
Replace Toner Cartridge Y.
Does the error recur when the power is turned
ON?
Go to Step[7]. End of procedure
7
ANTENNA CTRG operation check
Disconnect and then re-connect P/J415 on
PWBA MCU.
Does the error recur when the power is turned
ON?
Go to Step[8]. Go to Step[9].
8
Continuity check of HARNESS ASSY MAIN
Disconnect the P/J415 from PWBA MCU.
Do all of the wiring below have normal
continuity?
J415-1 ↔ J106-2
J415-2 ↔ J106-1
Go to Step[9]. Repair broken or
shorted part.
9
Check after replacement of HOUSING
ASSY-DEVE Y
Replace HOUSING ASSY-DEVE Y. (p.410)
Does the error recur when the power is turned
ON?
Go to Step[10]. End of procedure
10
Check after replacement of ANTENNA
ASSY-CTRG or ANTENNA CTRG
Replace ANTENNA ASSY-CTRG or
ANTENNA CTRG. (p.405) or (p.407)
Does the error recur when the power is turned
ON?
Replace PWBA
MCU. (p.432)
End of procedure
Step Check Yes No
To Next Page
