EPSON AcuLaser CX11/CX11F Revision B
52
1.3.2 Basic Functions
1.3.2.1 Print Mode
BUTTON FUNCTIONS
Note *1: All the modes become inoperative when system error occurred.
*2: If the error that requires user intervention to be cleared has occurred, users cannot switch modes until they cancel the error.
If there is an error concerning device that is diagnosed as device failure at start-up, switching between modes is impossible.
Button name Idling During printing Twain Fax printing Error
*1,2
Copy button Moves to copy mode Invalid Invalid Warning is displayed when receiving data
from the fax board. After receiving the data,
the current mode can be switched.
Unable to move to copy mode. In
copy mode, switches to print mode.
FAX button Moves to fax mode Moves to fax mode Invalid Moves to fax mode Moves to fax mode. In fax mode,
switch to print mode.
Scan button Moves to scan mode Moves to scan mode Invalid Moves to scan mode Moves to scan mode. In scan mode,
switch to print mode.
Setup button Moves to setup mode Waits for the engine to stop,
and moves to setup mode.
Invalid Waits for the engine to stop, and moves to
setup mode.
Moves to setup mode. In setup mode,
switch to print mode.
One touch speed dial A/
One touch speed dial B/
One touch speed dial C
Moves to fax mode,
and dials the registered
number.
Moves to fax mode, and
dials the registered number.
Invalid Moves to fax mode, and dials the registered
number.
Moves to fax mode, and dials the
registered number.
Advanced/Menu button Invalid Invalid Invalid Invalid Invalid
Reset button Invalid Invalid Invalid Multiple warnings detected Invalid
Up button/
Down button
Multiple warnings
detected
Multiple warnings detected Invalid Invalid Invalid
Left button/
Right button
Invalid Invalid Invalid Invalid Invalid
Speed dial button Invalid Invalid Invalid Invalid Invalid
Redial button Invalid Invalid Invalid Invalid Invalid
Cancel button Invalid 1. Short press:
Cancels Job
2. Long press (hold for
more than three
seconds)Cancels all jobs
Local: Invalid
Network: Turns the power off when scanning
is NOT in progress. During scanning, cancels
the scanning while keeping the power on.
When scanning and printing occur at the same
time, the former has priority.
1. Short press: Cancels Job
2. Long press (hold for more than three
seconds)Cancels all jobs
Invalid
Asterisk/Hash buttons Invalid Invalid Invalid Invalid Invalid
Ten-key Invalid Invalid Invalid Invalid Invalid
Start Buttons Invalid Invalid Local: InvalidStarts scanning when scanning is
NOT in progress. Invalid during scanning.
Invalid 1. Recoverable error: Clears the error
2. Unrecoverable error:
Displays [Error cannot be cleared].
