EPSON AcuLaser CX11/CX11F Revision B
59
 Details on Monochrome/Color Copy Settings
 Details on Image Adjustment Settings
 Advanced Copy Mode Setup Items
Document
type
Target document Mode characteristics
Image data processing Resolution
Moire
removal
Background
noise reducing
Outline
emphasizing
Scan
resolution
Print
resolution
Text/Photos Color documents printed by offset printing such as
magazines (moire normally occurs) and everyday office
documents.
Suitable for copying documents consisting black
characters and photographic images.
Yes Yes Yes 300dpi 600dpi
Photos Photos, printed materials that contains a lot of photos
and any other documents with images that need tone
reproduction.
Emphasizes color and density reproducibility. (High
quality mode that stresses gradation and contrast for
reproducing photo images.)
Yes NO 300dpi 600dpi
Text Documents mainly consist of black text. Performs black text enhancement process in order to
obtain best quality for the documents.
--- Yes --- 300dpi 600dpi
High
resolution
Technical drawings or any other detailed drawings that
consist of a lot of fine lines.
Performs black text enhancement process reducing the
background noise. Scan resolution is set to 600 dpi, the
maximum image quality mode for emphasis
reproducibility of the technical drawing, fine lines.
--- Yes --- 600dpi 600dpi
Adjustment
Item
Set contents Description
Setup value coverage
(-) side (+) side
Density Adjust the density of whole area of the image. Increase the density (darken the image): to + sideReduce the density (lighten the image): to - side -3 3
Contrast Adjust the contrast (difference between lights and
darks) applied to whole area of the image
Difference is small: to + side (increases contrast) Difference is large: to - side (decreases contrast)
-3 3
R Fine adjusts blue (deep blue) components Blue is weak: to - side (Increases G/B relatively by lowering R) Blue is strong: to + side (Decreases G/
B relatively by increasing R)
-3 3
G Fine adjusts red (purplish red) components Red is weak: to - side (Increases R/B relatively by lowering G) Red is strong: to + side (Decreases R/B
relatively by increasing G)
-3 3
B Fine adjusts yellow components Yellow is weak: to - side (Increases R/G relatively by lowering B)
Yellow is strong: to + side (Decreases R/G relatively by increasing B)
-3 3
Setup menu Remarks
Standard copy ---
2 Pages per Sheet ---
