EPSON AcuLaser CX11/CX11F Revision B
ADJUSTMENT Fax Function 542
5.3.2.1 Retrieving the User Data
With this function, the user-established data stored in the fax unit can be retrieved and
stored onto the computer by information type specifying the folders to save them.
 System Parameter Information
Relative addresses and the corresponding parameter settings are written in hexadecimal
onto the computer as shown below.
Figure 5-5. System Parameter Information
 Speed Dial Information
 Group Dial Information
 G3-ID Information/Header Information
The binary parameters are stored onto the computer without changing the format.
File Name File Name Description
BackUpDataYY-MM-DD SysParam.Txt
System Parameter Information
G3-ID.Bin
G3-ID information
TxHeader.Bin
Information in the fax header
SpeedDial.Bin
Speed Dial information
GroupDial.Bin
Group Dial information
OneTuch.Bin
One-Touch button information
C A U T I O N
Do not shuffle the order or delete the settings. Only changing the
setting values is allowed.
0x0000 = 08
0x0001 = 00
0x0002 = 00
0x0003 = 00
0x013E = 01
0x013F = 00
....
Relative Address
Parameter Setting
Stored name and fax number
(77 bytes)
XXH
Stored name and fax number
(77 bytes)
XXH
Speed-dial code (1 through 60) (1 byte)
Information assigned to the
group-dial code (65 bytes)
XXH
XXH
Group-dial code (1 through 20) (1 byte)
Information assigned
group-dial code (65
b
