Epson AcuLaser CX11 Service Manual

EPSON AcuLaser CX11/CX11F Revision B
APPENDIX Printer System Electrical Connection 566
7.2 Printer System Electrical Connection
7.2.1 Connector Summary
This section gives the connector summary for the AcuLaser CX11/CX11F and each
connector’s plug and jack alignment.
7.2.1.1 Plug and Jack Layout
IOT
Table 7-1. IOT
P/J Location Remarks
1 G-156
Connects PWBA FUSER CONT and HARNESS ASSY MAIN
2 G-156
Connects PWBA FUSER CONT and HARNESS ASSY AC
3 G-157
Connects PWBA FUSER CONT and HARNESS ASSY MCU C/L
100 F-122
Connects SWITCH-P/H and HARNESS ASSY P/H2
101 G-123
Connects SENSOR OHP and HARNESS ASSY P/H2
102 F-123
Connects SENSOR REGI and HARNESS ASSY P/H2
103 D-124
Connects SENSOR PAPER ENPTY and HARNESS ASSY P/H1
104 H-110
Connects SENSOR HUM&TEMP and HARNESS ASSY MAIN
105 D-108
Connects SENSOR ROTARY HOME POSI and HARNESS ASSY
MAIN
106 H-108
Connects ANTENNA CTRG and HARNESS ASSY MAIN
107 D-107
Connects SENSOR IBT RETRACT and HARNESS ASSY MAIN
108 D-106
Connects SENSOR TR-O and HARNESS-ASSY XERO
109 D-106
Connects ANTENNA ASSY and HARNESS ASSY XERO
111 G-137
Connects SENSOR FUSER IN and HARNESS ASSY 2BTR SENS
112 H-137
Connects SENSOR 2BTR RETRACT and HARNESS ASSY ADC
113 H-136
Connects SWITCH 2BTR COVER and HARNESS ASSY 2BTR SW
114 D-104
Connects SWITCH-INLK FUSER and HARNESS ASSY MAIN
115 G-107
Connects SWITCH-INLK FRONT and HARNESS ASSY MAIN
116 G-108
Connects SWITCH ASSY TOP and HARNESS ASSY MAIN
117 D-105
Connects SWITCH-INLK FUSER and HARNESS ASSY MAIN
125 G-108
Connects SWITCH-FRONT DOOR and HARNESS ASSY MAIN
126 F-138
Connects SENSOR TNER FULL and HARNESS ASSY TNER FULL
128 G-153
Connects FUSER LOCK SWITCH and HARNESS ASSY MAIN
200 H-153
Connects MOT ASSY P/R and HARNESS ASSY MAIN
201 G-153
Connects MOT ASSY P/R and HARNESS ASSY MAIN
202 F-124
Connects CLUTCH ASSY PRE REGI and HARNESS ASSY P/H2
203 F-122
Connects CLUTCH ASSY REGI and HARNESS ASSY P/H2
204 C-109
Connection in MOT ASSY ROT
400 I-149
Connects PWBA MCU and FFC-ASSY ESS
401 I-149
Connects PWBA MCU and FFC-ASSY LV/MCU
403 H-148
Connects PWBA MCU and HARNESS ASSY MAIN
404 H-148
Connects PWBA MCU and MOT ASSY FSR
405 H-148
Connects PWBA MCU and MOT ASSY MAG
406 H-149
Connects PWBA MCU and MOT ASSY MAG
407 H-149
Connects PWBA MCU and HARNESS ASSY MAIN
408 H-148
Connects PWBA MCU and HARNESS ASSY P/H1
409 H-148
Connects PWBA MCU and HARNESS ASSY P/H1
410 I-148
Connects PWBA MCU and HARNESS ASSY MAIN
411 I-148
Connects PWBA MCU and DRIVE ASSY PRO
412 I-148
Connects PWBA MCU and HARNESS ASSY MAIN
413 I-148
Connects PWBA MCU and HARNESS ASSY MAIN
414 I-147
Connects PWBA MCU and DRIVE ASSY PRO
415 J-147
Connects PWBA MCU and HARNESS ASSY MAIN
416 J-147
Connects PWBA MCU and HARNESS-ASSY XERO
417 I-147
Connects PWBA MCU and HARNESS ASSY MCU C/L
418 I-147
Connects PWBA MCU and HARNESS ASSY ADC
420 J-148
Not used
421 J-148
Connects PWBA MCU and HARNESS ASSY MAIN
422 I-147
Connects PWBA MCU and HARNESS ASSY ADC
429 D-109
Connects PWBA CRUM and HARNESS ASSY MAIN
Table 7-1. IOT
P/J Location Remarks
