EPSON AcuLaser CX11/CX11F Revision B
TROUBLESHOOTING Printer 251
3.4.5.2 Print Quality-related FIP Table
To reliably judge and understand the details of trouble, and perform the correct remedy
efficiently when printing quality-related trouble occurs, make a test print, and use the
FIP tables corresponding to the phenomena.
When trouble cannot be restored by the printing quality-related FIP, check again using
the FIP, and then replace all parts indicated in the “ESS and possible parts that caused
the error” one by one to check the parts and perform troubleshooting.
The printing quality-related FIPs describe typical troubles as below.
Table 3-12. Print Quality-related FIP Table
Symptom See FIP
Printing is Faint (Weak Tones) FIP-P1
Blank Print FIP-P2
Solid Black Print FIP-P3
Vertical White Bands or Lines FIP-P4
Horizontal White Bands or Lines FIP-P5
Vertical Black Lines FIP-P6
Horizontal Black Lines FIP-P7
Image is Partially Not Printed FIP-P8
Toner Smudges FIP-P9
Residual Image FIP-P10
Dark or Dirty Background FIP-P11
Skew Print FIP-P12
Print Paper Damage FIP-P13
Image Not Fixed FIP-P14
Color Shift FIP-P15
Uneven Density/Thin-Spot FIP-P16
Entirely Faint FIP-P17
Entirely Fogged in Black FIP-P18
Entirely Thin FIP-P19
Uneven Density in Horizontal Direction FIP-P20
Vertical White Lines (Location of the lines are same between Y, M, C and K) FIP-P21
Vertical White Lines (Locations of the lines are different between Y, M, C and K)
FIP-P22
Horizontal Lines FIP-P23
Stain FIP-P24
Colored Dots at 150mm Pitch FIP-P25
Vertical Two Lustered Streaks on the Center of OHP FIP-P26
5mm-width Horizontal Bands at 84.5mm Intaervals FIP-P27
