Epson AcuLaser CX11 Service Manual

EPSON AcuLaser CX11/CX11F Revision B
37
1.2.2.5 Consumables/Periodic Replacement Unit
SPECIFICATIONS
Note *1: Approximate number of printed pages using A4 continuous printing at 5% print rate.
The cartridge lifetime varies according to the paper size and type of printing (toner
save mode etc.)
*2: Monochrome : Color = 1 : 2, 2p/J, print rate 5% (A4)
The lifetime depends on printing method and the frequency of switching the power.
The life of the photoconductor unit is reduced by half when printing on LGL sized
paper only.
CONDITIONS FOR STORAGE AND TRANSPORT
 Temperature and humidity conditions
NOTE1: Non-condensing
2: Storage time after opening is 12 months in the normal operating environment.
 Storage altitude
65 to 101kPa (0 to 3100m)
(Withstands altitude of 0 to 15, 000 m while transported by air. However, this
assumes that the cargo compartment is maintained at 70.9275 kPa or higher.)
 Package dropping
There should be no damage on 1 corner, 3 edges, and 6 sides of the listed in the
table below by drop of 91 cm.
Table 1-24. Consumables and Components needing Periodic Replacement
Program Configurations Lifetime (pages)
External
dimensions (mm)
Weight
(kg)
Toner Cartridge
(Y, M, C, K)
Toner Cartridge 1500*
1
52.7 (W)
285.6 (D)
58.4 (H)
0.2
4000*
1
0.27
Photoconductor Unit Transfer belt
Photoconductor with
waste toner box
14000*2
B/W continuous:
42,000
F/C continuous:
10,500
310 (W)
280 (D)
110 (H)
2.8
Fuser unit Heat roller 100000 330 (W)
110 (D)
105 (H)
1.3
Developer unit Development roller K : 100000
Y/M/C: 66700
315 (W)
75 (D)
85 (H)
0.7
Second transfer unit Transfer roller 100000 315 (W)
35 (D)
15 (H)
0.2
Table 1-25. Temperature and humidity conditions
Status Temperature Humidity Guaranteed period
Normal
Conditions
0 to 35 degrees C 15 to 80 % RH
24 months
(unopened)
Severe
Conditions
High
temperature
35 to 40 degrees C High
humidity
80 to 95 % RH
Max. of 1 month
Low
temperature
-20 to 0 degrees C
Low
humidity
5 to 15 % RH
Table 1-26. Package dropping
Package name Drop
Toner Cartridge 91cm
Photoconductor unit + Transfer unit 91cm
Fuser unit 91cm
Developer unit 91cm
Second transfer unit 91cm
