EPSON AcuLaser CX11/CX11F Revision B
APPENDIX Printer System Electrical Connection 567
430 E-109
Connects PWB ASSY ROT and HARNESS ASSY MAIN
431 F-138
Connects SENSOR ASSY ADC and HARNESS ASSY ADC
432 D-109
Connects PWB ASSY ROT and HARNESS ASSY MAIN
433 D-109
Connects PWB ASSY ROT and PWB ASSY MOT
500 H-153
Connects LV/HVPS and FFC-ASSY LV/MCU
501 I-152
Connects LV/HVPS and HARNESS ASSY MAIN
502 I-153
Connects LV/HVPS and HARNESS ASSY MAIN
503 I-155
Connects LV/HVPS and HARNESS ASSY AC
D H-154
Connects LV/HVPS and WIRE ASSY BTR
F F-109
Connects LV/HVPS and WIRE ASSY 2BTR
G E-109
Connects PWBA HVPS and WIRE ASSY IBT
H E-109
Connects PWBA HVPS and WIRE ASSY DTN
A H-155
Connects LV/HVPS and WIRE ASSY BCR
C H-156
Connects LV/HVPS and WIRE ASSY DEVE
510 I-108
Connects HOLDER ASSY BIAS and WIRE ASSY DEVE
512 I-107
Connects GUIDE CRU ASSY and WIRE ASSY BTR
513 H-107
Connects GUIDE CRU ASSY AD and WIRE ASSY IBT
514 I-108
Connects GUIDE CRU ASSY AD and WIRE ASSY BCR
515 H-153
Connects LV/HVPS and HARNESS ASSY MAIN
516 F-110
Connects PWBA HVPS and HARNESS ASSY MAIN
600 F-153
Connects MOT ASSY MICRO and HARNESS ASSY MAIN
601 H-138
Connects ROS ASSY and HARNESS ASSY MAIN
602 H-138
Connects ROS ASSY and HARNESS ASSY MAIN
603 F-124
Connects HARNESS ASSY P/H1 and HARNESS ASSY P/H2
604 F-124
Connects MOTOR-PH and HARNESS ASSY P/H1
605 E-124
Connects SOLENOID PICK UP and HARNESS ASSY P/H1
607 E-140
Not used
614 E-105
Connects FUSER ASSY and HARNESS ASSY MCU C/L
617 D-140
Connects HARNESS-ASSY TNER FULL and HARNESS ASSY
MAIN
Table 7-1. IOT
P/J Location Remarks
620 H-137
Connects HARNESS ASSY 2BTR SENS and HARNESS ASSY ADC
621 I-136
Connects HARNESS ASSY 2BTR and HARNESS ASSY ADC
CN1 B-106
Connects OP PANEL and HARNESS ASSY PANEL
CN405 G-155
Connects PWBA ESS and HARNESS ASSY PANEL
CN410 G-156
Connects PWBA ESS and FAX BOARD
CN501 G-156
Connects PWBA ESS and HARNESS ASSY MAIN
CN502 F-155
Connects PWBA ESS and HARNESS ASSY MAIN
CN601 G-155
Connects PWBA ESS and FFC-ASSY ESS
CN602 G-155
Connects PWBA ESS and HARNESS ASSY MAIN
CN1 I-153
Connects LV/HVPS and HARNESS ASSY MAIN
CN701 G-155
Connects PWBA ESS and SCANNER
CN702 G-155
Connects PWBA ESS and SCANNER
CN703 G-156
Connects PWBA ESS and SCANNER
CN704 G-155
Connects PWBA ESS and SCANNER
CN705 G-155
Connects PWBA ESS and SCANNER
T2 I-107
Connects PLATE BIAS-2ND ASSY and WIRE ASSY 2BTR
T4 H-107
Connects GUIDE CRU ASSY AD and WIRE ASSY DTN
Table 7-1. IOT
P/J Location Remarks
