MAINTENANCE Printer Maintenance Function 556
 Error LogDisplays the latest 20 errors with the following information; panel
message, EJL status code, the number of pages, jam code, paper size, paper type,
and date/time.The 20 errors are listed in the order of number of pages form largest
to smallest. Service call errors which occurred after the Ready mode and jam
errors are listed. The errors with total pages which are the same as previously
recorded errors are not included.
 Jam Code
The location of the jam is indicated by 8-digit hexadecimal strings as bit data.
Table 6-1. Jam code
Bit Location of jam
31-24
---
23
At Exit sensor
22
At Fuser In sensor
21
At Regi sensor
20
At OHP sensor
19
At Tray Path1 sensor
18
At Tray Path2 sensor
17
At Dup In sensor
16
At Dup Out sensor
15
After Exit sensor turns off, Dup In sensor does not turn off
14
After Dup In sensor turns on, Dup Out sensor stays off
13
After Duplex loading signal, Regi sensor stays off
12
After Regi sensor turns on, Exit sensor stays off.
11
After Regi Roll turns on, Exit Fuser In sensor is stays off.
10
---
9
The setting is for transparency, but media other than transparencies
was fed. The setting is for other than transparency, but transparencies
were fed.
8
---
7
After Regi Roll turns on, Exit sensor stays off, Fuser In sensor off.
6
After Regi Roll turns on, Exit sensor is stays off, Fuser In sensor on.
5
After Regi Roll turns on, Regi sensor stays on.
4
Regi sensor signal from cassette 1 or 2 is not received.
3
Regi sensor signal from MP tray is not received.
2
Tray Path1 sensor signal from cassette 1 is not received.
1
(Tray Path1 sensor signal from cassette 2 is not received.)
0
(Tray Path2 sensor signal from cassette 2) is not received.
