Epson AcuLaser CX11 Service Manual

EPSON AcuLaser CX11/CX11F Revision B
OPERATING PRINCIPLES Printer Section Operating Principle 96
2.2.3 Drive Transmission Path
2.2.3.1 DRIVE ASSY FEED
Rotation of DRIVE ASSY FEED is transmitted as follows:
Figure 2-22. Drive Transmission Flow
Figure 2-23. Diagram of Drive Transmission Path
DRIVE ASSY FEED
CLUTCH ASSY FEED
ROLL ASSY TURN 500
GEAR FEED
ROLL ASSY FEED 500
500 FEEDER ASSY
Leg_Sec06_035EB
DRIVE ASSY FEED
GEAR FEEDCLUTCH ASSY FEED
FRONT
Leg_Sec06_042EB
