Epson AcuLaser CX11 Service Manual

EPSON AcuLaser CX11/CX11F Revision B
MAINTENANCE Consumables and Components needing Periodic Replacement 563
6.5.2 Regular Replacement Parts
Table 6-6. Maintenance Information on Regular Replacement Parts
Part Name Part Code Life (Pages) Service life indication
Part to be replaced
at the same time
Remedy after Replacement Remarks
FUSER ASSY
2090471 100000
Worn Fuser 2ND BTR ASSY Execute “Reset Fuser Counter” in
the Maintenance Menu to reset the
life counter.
While it can still be printed, it is
desirable to replace the unit. If
printing is continued, a paper
jam will occur at the fusing
section frequently because the
wear of the heat roller shaft
increases the torque of the heat
roller.
HOUSING
ASSY-DEVE
K 1292991 100000
Worn K Dev Unit PIVOT AD Execute “Reset X DvlpCounter”
(X=Y, M, C, or K) in the
Maintenance Menu to reset the life
counter.
After executing the counter reset,
open and close the Cover A. Do not
turn the printer off until the engine
completely stops.
 While it can still be printed,
it is desirable to replace the
unit.
 The “PIVOT AD” is packed
with the ASP “HOUSING
ASSY-DEVE”.
Y 1292994
66700
Worn Y Dev Unit PIVOT AD
M 1292996
Worn M Dev Unit PIVOT AD
C 1292999
Worn C Dev Unit PIVOT AD
2ND BTR ASSY
1292981 100000
---
FUSER ASSY Execute “Reset 2ndBTRCounter” in
the Maintenance Menu to reset the
life counter.
After executing the counter reset,
open and close the Cover A. Do not
turn the printer off until the engine
completely stops.
While it can still be printed after
the message is displayed, it is
desirable to replace the unit.
