EPSON AcuLaser CX11/CX11F Revision B
OPERATING PRINCIPLES Printer Section Operating Principle 99
2.2.3.4 MOTOR ASSY DUP
Rotation of MOTOR ASSY DUP is transmitted as follows:
Figure 2-28. Drive Transmission Flow
Figure 2-29. Diagram of Drive Transmission Path
MOTOR ASSY DUP MOTOR ASSY DUP INV
GEAR 40/42
GEAR 36
GEAR 48H
GEAR 40/42
TRANSPORT ASSY DUP
INVERTER ASSY DUP
GEAR 36
GEAR 36
GEAR 30 OW
GEAR 36
ROLLER ASSY DUP OUT
GEAR 30
ROLLER ASSY DUP
GEAR 48H
GEAR 20/21H
GEAR 36
GEAR 30
ROLLER ASSY INVERTER
Leg_Sec06_038FB
GEAR 30
GEAR 30
GEAR 36
GEAR 20/21H
GEAR 48H
MOTOR ASSY DUP INV
INVERTER ASSY DUP
TRANSPORT ASSY DUP
GEAR 36
GEAR 36
GEAR 40/42
GEAR 48H
MOTOR ASSY DUP
GEAR 40/42
GEAR 36
GEAR 36
GEAR 30 OW
FRONT
Leg_Sec06_041FC
