Epson AcuLaser CX11 Service Manual

EPSON AcuLaser CX11/CX11F Revision B
APPENDIX Fax Unit System 641
PHONE LINE
Table 7-18. List of System Parameter (Phone Line)
Label
Maintenance
Code
User
Access
Internal
Address
Description Setting Value Default Remarks
Main Sub
LIN_DIAL_TYPE 300 001
{
050
Dial type
0 = PB ( DTMF )
1 = DP ( 10 PPS )
2 = DP ( 20 PPS )
PB
(0)
---
LIN_RX_MODE 300 005
{
051
Reception mode 0 = reserVe
1 = Fax only
2 = Auto switch
3 = Phone only
4 = TAM
Auto switch
(2)
---
LIN_LINE_TYPE 300 007
{
052
Line type 0 = PSTN (Public Switched Telephone
Network)
1 = PBX (Private Branch Exchange)
PSTN
(0)
---
LIN_PBX_TO_PSTN 300 013
{
053
PSTN connection method 0 =Numbers
1 =Not numbers (earth start/flash start)
Numbers
(0)
---
LIN_FLASH_ENABLE 300 014
---
054
Flash start enabling or disabling 0 = Disable
1 = Enable
Disable
(0)
---
LIN_RING_CYCLE_MIN 300 015
---
055
Minimum ringer frequency 0 ~ 127.5 ms (1step = 0.5ms)
14ms
(28)
---
LIN_RING_CYCLE_MAX 300 016
---
056
Maximum ringer frequency 0
~ 127.5 ms (1step = 0.5ms)
100m
(200)
---
LIN_MAKE_10PPS 300 017
---
057
10 PPS Make time
Make time for dialing at DP (10 PPS)
0 ~ 255 ms (1step = 0.417ms)
31.275ms
(75)
---
LIN_BREAK_10PPS 300 018
---
058
10 PPS Break time
Break time for dialing at DP (10 PPS)
0
~ 255 ms (1step = 0.417ms)
67.137ms
(161)
---
LIN_MAKE_20PPS 300 019
---
059
16/20 PPS Make time
Make time for dialing at DP (16/20 PPS)
0 ~ 255 ms (1step = 0.417ms)
16.263ms
(39)
---
LIN_BREAK_20PPS 300 020
---
05A
16/20 PPS Break time
Break time for dialing at DP (16/20 PPS)
0
~ 255 ms (1step = 0.417ms)
33.777ms
(81)
---
LIN_DP_PAUSE_TIME 300 021
---
05B
DP interdigit time
The time between output digits for DP dialing
0 ~ 5100 ms (1step = 20ms)
720ms
(36)
---
LIN_PAUSE_WAIT_TIME 300 022
---
05C
Pose wait time
Wait time for pose signal
0 to 25.5 sec(1 step = 100 ms) 4 seconds
(40)
---
LIN_BUSYTONE_DETECTION 300 023
---
05D
Enables or disables detecting busy tone at the time of dialing 0 = Disable
1 = Enable
Disable
(0)
---
LIN_BLIND_TIME 300 026
---
05E
Blind time when performing blind dialing 0 to 255 sec (1 step = 1 sec) 5 seconds
(5)
---
