Epson AcuLaser CX11 Service Manual

EPSON AcuLaser CX11/CX11F Revision B
APPENDIX Fax Unit System 642
LIN_DIALTONE_DETECT_TIME 300 027
---
05F
Dial tone detecting time out 0 to 255 sec (1 step = 1 sec) 20 seconds
(20)
---
LIN_RING_DETECT_TIME 300 030
---
060
Ring detecting time
The time from detecting ring until it is judged as dialing
100 to 2550 ms (1 step = 10 ms)
180ms
(18)
---
LIN_ONHOOK_DETECT_TIME 300 031
---
061
Off-hook detection time
Time limit for attached phone off-hook condition to regard it as a
shut-off signal
200 to 5100 ms (1 step = 20 ms)
1300ms
(65)
---
LIN_DIALTONE_DETECTION 300 032
---
062
Enables or disables detection of dial tone
Select whether detect or not detect dial tone immediately after
detecting off-hook condition when the line type is set to PSTN.
When this is set to “disable”, blind dialing is perfomed.
0 = Enable (detect)
1 = Disable (not detect)
Disable
(1)
---
LIN_DIALTONE_FREQ 300 033
---
063
Dial tone frequency 0 = 350 to 450Hz
1 = 300 to 500Hz
2 = 450 to 650Hz
400Hz
(0)
---
LIN_BUSYTONE_FREQ 300 034
---
064
Busy tone frequency 0 = 400Hz
1 = 350 to 450Hz
2 = 300 to 500Hz
3 = 450 to 650Hz
400Hz
(0)
---
LIN_BUSYTONE_PATTERN 300 035
---
065
Busy tone pattern 0 = ON 0.30 ~ 0.80S
OFF 0.30
~ 0.80S
1 = ON 0.20
~ 0.60S
OFF 0.30
~ 0.60S
2 = ON 0.50
~ 1S
OFF 0.50
~ 1S
3 = ON 0.12
~ 1.2S
OFF 0.12
~ 1.2S
(0)
---
LIN_NCU_TYPE 300 036
---
066
NCU type 0 = For Japan
(0)
Not used
LIN_20PPS_ENABLE 300 037
---
067
Enables or disables 20 PPS setting
When this is set to “disable”, 20 PPS setting specified in the dial
type setting (300-001) becomes invalid.
0 = Enable
1 = Disable
Enable
(0)
---
LIN_DP_RELAY_DELAY 300 038
---
068
Waiting time until the line stabilizes when performing pulse dialing 0 to 2550 ms (1 setp = 10 ms)
10ms
(1)
---
LIN_DIAL_NG_NUMBER 300 039
---
069
Allows or not allows to store emergency phone number into the
speed-dial memory
Emergency phone number: XXXXX
0 = Allows
1 = Not allows
Allows
(0)
Fixed to 0
Not used
LIN_RING_INVALID_TIME 300 040
---
06A
Time for judging ring signal is OFF
The time limit for ring signal. The line is shut-off if the time exceeds
the set value.
0 to 2550 ms (1 step = 10 ms)
0 = 125 ms
125ms
(0)
---
Table 7-18. List of System Parameter (Phone Line)
Label
Maintenance
Code
User
Access
Internal
Address
Description Setting Value Default Remarks
