EPSON AcuLaser CX11/CX11F Revision B
APPENDIX Parts List 589
04-01-22 GEAR PICK UP
04-01-23 SOLENOID PICK UP
04-01-24 SENSOR UPPER PASS
04-01-25 ACUTUATOR EMPTY
04-01-26 HARNESS-ASSY P/H1
05-01-01 COVER-PH
05-01-02 CHUTE ASSY-REAR
05-02-01 FRAME ASSY-PH
05-02-02 CLUTCH ASSY REGI
05-02-06 GEAR-REGI
05-02-08 ROLL REGI RUBBER
05-02-11 VARISTOR
05-02-12 ROLL ASSY-PRE REGI
05-02-16 SENSOR
05-02-17 SPRING-ACTUATOR
05-02-18 ACTUATOR-REGI
05-02-19 SENSOR UPPER PASS
05-02-20 MOTOR-PH
05-02-21 HARNESS ASSY P/H2
05-02-22 CLUTCH ASSY REGI
05-02-23 EXIT CHUTE SWITCH
05-02-24 DRIVE ASSY PH
05-02-25 COVER HARNESS
06-01-01 CHUTE ASSY-FSR
06-01-03 SENSOR
06-01-04 HARNESS ASSY 2BTR SENS
06-01-06 DIODE FUSER
06-01-07 FRAME ASSY-2ND
Table 7-5. Main Unit
Diagram No. Part Name
06-01-08 GEAR 27
06-01-12 2ND BTR ASSY
06-01-13 CAM ASSY-2ND
06-01-15 COVER ASSY-RR 2ND
06-01-16 HARNESS ASSY 2BTR SW
06-01-18 EXIT CHUTE SWITCH
06-01-20 SENSOR ASSY ADC
06-01-21 HOLDER-ADC 2ND
06-01-22 SENSOR UPPER PASS
06-01-26 SENSOR UPPER PASS
06-01-27 PLATE BIAS-2ND ASSY
06-01-29 CAM ASSY-IBT CL
06-01-30 HARNESS ASSY ADC
07-01-02 SENSOR TR-0
07-01-04 GUIDE CRU ASSY D
07-01-12 HARNESS ASSY XERO
07-01-13 GUIDE CRU ASSY AD
07-01-15 LEVER-LATCH PR
07-01-16 CAP-PLATE PR
07-01-20 BCR CLN XERO ASSY
07-01-24 SENSOR TNER FULL
07-01-27 GUIDE CRU
07-01-30 WIRE ASSY IBT
07-01-31 WIRE ASSY BTR
07-01-32 WIRE ASSY BCR
07-01-33 WIRE ASSY DTN
08-01-01 ROS ASSY
08-01-02 CLEANER ASSY
Table 7-5. Main Unit
Diagram No. Part Name
