Epson AcuLaser CX11 Service Manual

EPSON AcuLaser CX11/CX11F Revision B
TROUBLESHOOTING Printer 220
9
Check after replacement of PWBA FUSER
CONT
Replace PWBA FUSER CONT. (p.439)
Does the error occur when the power is turned
ON?
Go to Step [10]. End of procedure
10
Check after replacement of LV/HVPS
Replace LV/HVPS. (p.435)
Does the error occur when the power is turned
ON?
Go to Step [11]. End of procedure
11
Continuity check of HARNESS ASSY MAIN
Disconnect P/J1 from PWBA FUSER CONT,
and P/J410 from PWBA MCU.
Do all of the wiring below have normal
continuity?
P/J1-1 ↔ P/J410-10
P/J1-3 ↔ P/J410-9
Replace PWBA
MCU. (p.432)
Replace
HARNESS
ASSY MAIN
Step Check Yes No
