EPSON AcuLaser CX11/CX11F Revision B
DISASSEMBLY AND ASSEMBLY Printer 307
REINSTALLATION
1. Install the SCANNER on the main unit.
2. Secure the SCANNER to the main unit with five screws (silver-with flange-8mm x 4,
silver-no flange-8mm x 1).
3. Secure the SPRING SC FFC to the main unit with the two screws (silver, with flange,
8 mm).
4. Secure the harnesses of the SCANNER with the clamp.
5. Secure the WIRE GROUND of the SCANNER with the screw (silver, with flange, 8
mm).
6. Connect the five connectors (CN701 to CN705) to the PWBA ESS.
7. Secure the COVER LEG LH OUTER with the two screws (silver, with flange, 8 mm)
to the main unit together with the HINGE COVER L.
8.
Attach the COVER ASSY LH.
(p321)
9. Attach the accordion shaped rubber covers (HINGE COVER L, HINGE COVER
R) to the left and right hinge sections.
C A U T I O N
When securing the two SPRING SC FFCs, make sure that the part
of the SCANNER harnesses with black tape are located between the
two SPRING SC FFCs.
C H E C K
P O I N T
When reassembling the AcuLaser CX11F (fax model), removing the
fax module in advance make it easier to connect CN701, CN702, and
CN704 to the PWBA ESS.
C A U T I O N
îš„ The CN701, CN702, and CN704 FFCs are resemble each other
in shape as their pin numbers are so close; 14, 13, and 12
respectively. Be careful not to connect them wrongly.
îš„ When reassembling the AcuLaser CX11F (fax model), make
sure to put CN701 (14-pin) and CN702 (13-pin) FFCs through
the FERRITE CORE.
To Next Page
