EPSON AcuLaser CX11/CX11F Revision B
DISASSEMBLY AND ASSEMBLY Printer 309
REINSTALLATION
1. Attach COVER ASSY TOP to the main unit with the COVER ASSY TOP opened.
2. Secure STOPPER PLATE to the main unit with the screw (silver, with flange, 8mm).
3. Fasten COVER ASSY TOP with the 2 E-rings.
4. Fit COVER LEG LH INNER to the main unit.
5. Secure COVER LEG LH INNER to the main unit with the screw (silver, with flange, 8
mm).
6. Fit COVER LEG LH OUTER to the main unit.
7. Secure COVER SIDE LH ASSY to the main unit with the 2 screws (silver, with flange,
8 mm).
8. Install Fuser ASSY. (p415)
9. Attach COVER ASSY RH.. (p326)
10. Attach COVER ASSY RH.. (p321)
C A U T I O N
When performing the following work, use the outer of the two
grooves located on the stud.
