EPSON AcuLaser CX11/CX11F Revision B
DISASSEMBLY AND ASSEMBLY Printer 402
REINSTALLATION
1. Match the boss on ROS ASSY with the hole on the main unit, and attach ROS
ASSY.
2. Fasten ROS ASSY to the main unit with the 5 screws (silver, with flange, 10mm).
3. Connect connector (P/J601) and connector (P/J602) to ROS ASSY.
4. Attach CLEANER ASSY. (p403)
5. Attach FRAME ASSY-PH. (p352)
6. Attach COVER INNER L. (p327)
7. Attach COVER FRONT L and COVER FRONT ASSY U. (p318)
8. Attach COVER MSI. (p317)
9. Attach COVER ASSY LH. (p321)
10. Attach COVER ASSY RH. (p326)
C A U T I O N
When performing the following work, press LATCH ROTARY on
LATCH ASSY-ROTARY to release the latch, turn FRAME ASSY-
ROTARY by hand, and move HOUSING ASSY-DEVE to prevent
contact with MAG ROLL.
