Epson AcuLaser CX11 Service Manual

EPSON AcuLaser CX11/CX11F Revision B
DISASSEMBLY AND ASSEMBLY Printer 418
REINSTALLATION
1. Match the protrusion and hook on FUSER LOCK SWITCH with the hole on the
main unit, slide FUSER LOCK SWITCH to the left, and attach FUSER LOCK
SWITCH.
2. Putting your hand beneath FUSER LOCK SWITCH to prevent it from dropping,
fasten FUSER LOCK SWITCH with the screw (silver, with flange, tapping, 6
mm).
3. Bring out the connector on FUSER LOCK SWITCH to the outside from the hole
on the main unit.
4. Attach the connector (P/J128, blue) to FUSER LOCK SWITCH, and fasten the
harness on FUSER LOCK SWITCH with the two clamps.
5. Attach CHUTE ASSY-FSR and COVER ASSY-RR 2ND. (p366)
6. Attach COVER ASSY LH. (p321)
7. Attach FUSER ASSY. (p415)
C A U T I O N
When performing the following, take care not to damage FUSER
LOCK SWITCH by falling or dropping it.
