EPSON AcuLaser CX11/CX11F Revision B
DISASSEMBLY AND ASSEMBLY Printer 425
REINSTALLATION
1. Match the boss on MOT ASSY ROT with the hole on the main unit, and attach.
2. Fasten MOT ASSY ROT to the main unit with the 4 screws (silver, with flange, 6
mm).
3. Connect connector (P/J433) to PWB ASSY ROT.
4. Fasten WIRE ASSY DEVE with the clamp.
5. Attach LV/HVPS. (p435)
6. Attach COVER FRONT L and COVER FRONT ASSY U. (p318)
7. Attach COVER MSI. (p317)
8. Attach COVER ASSY LH. (p321)
9. Attach COVER ASSY RH. (p326)
C A U T I O N
When doing the following work, take care so that WIRE ASSY
DEVE, WIRE ASSY BTR, and FFC-ASSY ESS are not sandwiched
between the main unit and MOT ASSY ROT.
Table 4-10. Symptoms when the connector is loose
Connector
No.
Panel Indication Symptom
Error Caused by Connector
Disconnection
P/J433
Service Req E527 All LEDs flash
---
