Epson AcuLaser CX11 Service Manual

EPSON AcuLaser CX11/CX11F Revision B
DISASSEMBLY AND ASSEMBLY Printer 436
Table 4-15. Symptoms when the connector is loose
Connector
No.
Panel Indication Symptom
Error Caused by Connector
Disconnection
P/J500
Ready → Service
Req E537
All LEDs flash ---
P/J501 --- Printing is not possible. ---
P/J502 Service Req C0998 All LEDs light ---
P/J503 --- Printed light and faint ---
P/J510
Release Cariage
Lock
Printed light and faint ---
P/J515 Ready Entirely Faint FIP-P17
A (508) Ready Entirely Fogged in Black FIP-P18
C (509) Ready Entirely Faint FIP-P17
D (504) Ready
Uneven Density/Thin-
Spot
FIP-P16
