EPSON AcuLaser CX11/CX11F Revision B
DISASSEMBLY AND ASSEMBLY Printer 470
REINSTALLATION
1. Attach STOPPER CST L. (p471)
2. Match the boss on GUIDE CST L with the hole on 500 PAPER FEEDER ASSY
while inserting SWITCH FEEDER DOOR into the hole on the rear of GUIDE
CST L, and attach GUIDE CST L.
3. Fasten GUIDE CST L to 500 PAPER FEEDER ASSY with the 5 screws (silver,
tapping, 6mm).
4. Match the boss on CAP FEEDER with the hole on 500 PAPER FEEDER ASSY,
and attach CAP FEEDER.
5. Fasten CAP FEEDER to 500 PAPER FEEDER ASSY with the screw (silver,
tapping, 8 mm).
6. Attach CHUTE ASSY 500. (p462)
7. Attach HOUSING ASSY FEED. (p472)
8. Attach DRIVE ASSY FEED. (p454)
9. Attach CLUTCH ASSY FEED. (p457)
10. Attach COVER LEFT 500. (p449)
11. Attach COVER RIGHT 500. (p451)
12. Attach CHUTE FDR ASSY 500. (p450)
13. Attach 500 PAPER CASSETTE ASSY. (p442)
