EPSON AcuLaser CX11/CX11F Revision B
DISASSEMBLY AND ASSEMBLY Printer 476
REINSTALLATION
1. Insert the shaft on ACTUATOR NO PAPER CST from the notch on HOUSING
ASSY FEED.
2. Fit the shaft on ACTUATOR NO PAPER CST onto the hook on HOUSING
ASSY FEED while inserting ACTUATOR NO PAPER CST into the sensor on
SENSOR NO PAPER, and attach.
3. Attach COVER FEED to HOUSING ASSY FEED.
4. Fasten COVER FEED to HOUSING ASSY FEED with the 2 screws (silver,
tapping, 8 mm).
5. Match the hole on CAP ACTUATOR with the boss on HOUSING ASSY FEED,
and attach CAP ACTUATOR.
6. Attach HOUSING ASSY FEED. (p472)
7. Attach DRIVE ASSY FEED. (p454)
8. Attach CLUTCH ASSY FEED. (p457)
9. Attach COVER LEFT 500. (p449)
10. Attach 500 PAPER CASSETTE ASSY. (p442)
C A U T I O N
When performing the following work, pay attention to the
positional relationship between SENSOR NO PAPER and
ACTUATOR NO PAPER CST.
