EPSON AcuLaser CX11/CX11F Revision B
DISASSEMBLY AND ASSEMBLY ADF Section 510
REINSTALLATION
1. Secure the MOTOR to the MOTOR CUSHION with the two screws (M3 x 6 mm,
G-type, C-head, W/spring washer, W/Φ5 flat washer).
2. Secure the MOTOR CUSHION to the ADF FRAME ASSY with the two screws
(M3 x 6 mm, S-type, A-head).
3. Wind the harnesses of the MOTOR around the ferrite core once, and secure the
ferrite core to the harness with a tie wrap.
4. Bundle the harnesses and the grounding wire of the MOTOR with a tie wrap.
5. Attach the ADF BASE ASSY. (p498)
6. Attach the ADF COVER C. (p496)
7. Attach the PAPER GUIDE ASSY. (p526)
8. Attach the ADF COVER R. (p492)
9. Attach the ADF Unit. (p481)
10. Install the Scanner. (p306)
C A U T I O N
Make sure to attach the MOTOR CUSHION to the ADF FRAME
ASSY positioning the MOTOR CUSHION as shown in
Figure 4-195.
