Chapter 7: Quality of Service Commands 671
If you specify an IP ACL number or name, the following information displays:
Note
Only the access list fields that you configure are displayed. Thus, the command
output varies based on the match criteria configured within the rules of an ACL.
Direction Shows whether the ACL is applied to traffic coming
into the interface (ingress) or leaving the interface
(egress).
Interface(s) Identifies the interface(s) to which the ACL is
applied (ACL interface bindings).
VLAN(s) Identifies the VLANs to which the ACL is applied
(ACL VLAN bindings).
Term Definition
Rule Number The number identifier for each rule that is defined
for the IP ACL.
Action The action associated with each rule. The possible
values are Permit or Deny.
Match All Indicates whether this access list applies to every
packet. Possible values are True or False.
Protocol The protocol to filter for this rule.
ICMP Type
Note
This is shown only if the protocol is ICMP.
The ICMP message type for this rule.
Starting Source L4
port
The starting source layer 4 port.
Ending Source L4
port
The ending source layer 4 port.
Term Definition
