Agilent Technologies InfiniiVision 3000 X-Series Programmer's Guide

Root (:) Commands 6
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 203
:MTERegister[:EVENt] (Mask Test Event Event Register)
(see page 1138)
Query Syntax
:MTERegister[:EVENt]?
The :MTERegister[:EVENt]? query returns the integer value contained in
the Mask Test Event Event Register and clears the register.
Return Format
<value><NL>
<value> ::= integer in NR1 format.
See Also • "Introduction to Root (:) Commands" on page 190
• ":CHANnel<n>:PROTection" on page 276
• ":OPEE (Operation Status Enable Register)" on page 205
• ":OPERegister:CONDition (Operation Status Condition Register)" on
page 207
• ":OVLenable (Overload Event Enable Register)" on page 211
• ":OVLRegister (Overload Event Register)" on page 213
Table 71 Mask Test Event Event Register
Bit Name Description When Set (1 = High = True), Indicates:
15-11 --- --- (Not used.)
10 Auto
Mask
Auto Mask Created Auto mask creation completed.
9 --- --- (Not used.)
8 Started Mask Testing Started Mask testing started.
7-2 --- --- (Not used.)
1 Fail Mask Test Fail The mask test failed.
0Comple
te
Mask Test Complete The mask test is complete.
7R07(ELWLQ
2SHUDWLRQ6WDWXV
&RQGLWLRQ5HJLVWHU

25
07(HQDEOH
07(HQDEOH"
0DVN7HVW(YHQW(QDEOH0DVN5HJ


07(5HJLVWHU>(9(1W@"
0DVN7HVW(YHQW(YHQW5HJLVWHU
)DLO
&RP
SOHWH
$XWR
0DVN
6WDUWHG
