Agilent Technologies InfiniiVision 3000 X-Series Programmer's Guide

:SBUS<n> Commands 27
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 707
:SBUS<n>:IIC Commands
NOTE
These commands are only valid when the low-speed IIC and SPI serial decode option
(Option LSS) has been licensed.
Table 104 :SBUS<n>:IIC Commands Summary
Command Query Options and Query Returns
:SBUS<n>:IIC:ASIZe
<size> (see page 708)
:SBUS<n>:IIC:ASIZe?
(see page 708)
<size> ::= {BIT7 | BIT8}
:SBUS<n>:IIC[:SOURce]
:CLOCk <source> (see
page 709)
:SBUS<n>:IIC[:SOURce]
:CLOCk? (see
page 709)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> } for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:IIC[:SOURce]
:DATA <source> (see
page 710)
:SBUS<n>:IIC[:SOURce]
:DATA? (see page 710)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> } for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:IIC:TRIGger:
PATTern:ADDRess
<value> (see
page 711)
:SBUS<n>:IIC:TRIGger:
PATTern:ADDRess? (see
page 711)
<value> ::= integer or <string>
<string> ::= "0xnn" n ::= {0,..,9
| A,..,F}
:SBUS<n>:IIC:TRIGger:
PATTern:DATA <value>
(see page 712)
:SBUS<n>:IIC:TRIGger:
PATTern:DATA? (see
page 712)
<value> ::= integer or <string>
<string> ::= "0xnn" n ::= {0,..,9
| A,..,F}
:SBUS<n>:IIC:TRIGger:
PATTern:DATa2 <value>
(see page 713)
:SBUS<n>:IIC:TRIGger:
PATTern:DATa2? (see
page 713)
<value> ::= integer or <string>
<string> ::= "0xnn" n ::= {0,..,9
| A,..,F}
:SBUS<n>:IIC:TRIGger:
QUALifier <value>
(see page 714)
:SBUS<n>:IIC:TRIGger:
QUALifier? (see
page 714)
<value> ::= {EQUal | NOTequal |
LESSthan | GREaterthan}
:SBUS<n>:IIC:TRIGger[
:TYPE] <type> (see
page 715)
:SBUS<n>:IIC:TRIGger[
:TYPE]? (see
page 715)
<type> ::= {STARt | STOP | READ7
| READEprom | WRITe7 | WRITe10 |
NACKnowledge | ANACk | R7Data2 |
W7Data2 | RESTart}
