:TRIGger Commands 31

Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 903

:TRIGger[:EDGE]:LEVel

(see page 1138)

Command Syntax

:TRIGger[:EDGE]:LEVel <level>

<level> ::= <level>[,<source>]

<level> ::= 0.75 x full-scale voltage from center screen in NR3 format

for internal triggers

<level> ::= ±(external range setting) in NR3 format

for external triggers

<level> ::= ±8 V for digital channels (MSO models)

<source> ::= {CHANnel<n> | EXTernal} for the DSO models

<source> ::= {CHANnel<n> | DIGital<d> | EXTernal}

for the MSO models

<n> ::= 1 to (# analog channels) in NR1 format

<d> ::= 0 to (# digital channels - 1) in NR1 format

The :TRIGger[:EDGE]:LEVel command sets the trigger level voltage for the

active trigger source.

Query Syntax

:TRIGger[:EDGE]:LEVel? [<source>]

The :TRIGger[:EDGE]:LEVel? query returns the trigger level of the current

trigger source.

Return Format

See Also • "Introduction to :TRIGger Commands" on page 877

• ":TRIGger[:EDGE]:SOURce" on page 906

• ":EXTernal:RANGe" on page 320

• ":POD<n>:THReshold" on page 527

• ":DIGital<d>:THReshold" on page 295

NOTE

If the optional source is specified and is not the active source, the level on the active source

is not affected and the active source is not changed.
