Agilent Technologies InfiniiVision 3000 X-Series Programmer's Guide

80 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:DIGitize
[<source>[,..,<source
>]] (see page 199)
n/a <source> ::= {CHANnel<n> |
FUNCtion | MATH | SBUS{1 | 2}}
for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> | POD{1 | 2} | BUS{1 |
2} | FUNCtion | MATH | SBUS{1 |
2}} for MSO models
<source> can be repeated up to 5
times
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:MTEenable <n> (see
page 201)
:MTEenable? (see
page 201)
<n> ::= 16-bit integer in NR1
format
n/a :MTERegister[:EVENt]?
(see page 203)
<n> ::= 16-bit integer in NR1
format
:OPEE <n> (see
page 205)
:OPEE? (see page 206) <n> ::= 15-bit integer in NR1
format
n/a :OPERregister:CONDiti
on? (see page 207)
<n> ::= 15-bit integer in NR1
format
n/a :OPERegister[:EVENt]?
(see page 209)
<n> ::= 15-bit integer in NR1
format
:OVLenable <mask>
(see page 211)
:OVLenable? (see
page 212)
<mask> ::= 16-bit integer in NR1
format as shown:
Bit Weight Input
--- ------ ----------
10 1024 Ext Trigger Fault
9 512 Channel 4 Fault
8 256 Channel 3 Fault
7 128 Channel 2 Fault
6 64 Channel 1 Fault
4 16 Ext Trigger OVL
3 8 Channel 4 OVL
2 4 Channel 3 OVL
1 2 Channel 2 OVL
0 1 Channel 1 OVL
n/a :OVLRegister? (see
page 213)
<value> ::= integer in NR1
format. See OVLenable for <value>
Table 3 Root (:) Commands Summary (continued)
Command Query Options and Query Returns
