:SBUS<n> Commands 27

Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 667

:SBUS<n>:CAN:TRIGger:PATTern:ID

(see page 1138)

Command Syntax

:SBUS<n>:CAN:TRIGger:PATTern:ID <string>

<string> ::= "nn...n" where n ::= {0 |1|X|$}

<string ::= "0xnn...n" where n ::= {0,..,9 | A,..,F | X | $}

The :SBUS<n>:CAN:TRIGger:PATTern:ID command defines the CAN

identifier pattern resource according to the string parameter. This pattern,

along with the identifier mode (set by the

:SBUS<n>:CAN:TRIGger:PATTern:ID:MODE command), control the identifier

pattern searched for in each CAN message.

If the string parameter starts with "0x", it is a hexadecimal string made up

of hexadecimal and X (don't care) characters; otherwise, it is a binary

string made up of 0, 1, and X (don't care) characters.

Query Syntax

:SBUS<n>:CAN:TRIGger:PATTern:ID?

The :SBUS<n>:CAN:TRIGger:PATTern:ID? query returns the current settings

of the specified CAN identifier pattern resource in the 29- bit binary string

format.

Return Format

<string><NL> in 29-bit binary string format

Errors • "- 241, Hardware missing" on page 1099

See Also • "Introduction to :TRIGger Commands" on page 877

• ":SBUS<n>:CAN:TRIGger:PATTern:ID:MODE" on page 668

• ":SBUS<n>:CAN:TRIGger:PATTern:DATA" on page 665

NOTE

The ID pattern resource string is always 29 bits. Only 11 of these bits are used when the

:SBUS<n>:CAN:TRIGger:PATTern:ID:MODE is STANdard.

A string longer than 29 bits is truncated to 29 bits when setting the ID pattern resource.
