Agilent Technologies InfiniiVision 3000 X-Series Programmer's Guide

Commands Quick Reference 4
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 89
:DVM:MODE <mode> (see
page 314)
:DVM:MODE? (see
page 314)
<dvm_mode> ::= {ACRMs | DC |
DCRMs | FREQuency}
:DVM:SOURce <source>
(see page 315)
:DVM:SOURce? (see
page 315)
<source> ::= {CHANnel<n>}
<n> ::= 1-2 or 1-4 in NR1 format
Table 11 :DVM Commands Summary (continued)
Command Query Options and Query Returns
Table 12 :EXTernal Trigger Commands Summary
Command Query Options and Query Returns
:EXTernal:BWLimit
<bwlimit> (see
page 318)
:EXTernal:BWLimit?
(see page 318)
<bwlimit> ::= {0 | OFF}
:EXTernal:PROBe
<attenuation> (see
page 319)
:EXTernal:PROBe? (see
page 319)
<attenuation> ::= probe
attenuation ratio in NR3 format
:EXTernal:RANGe
<range>[<suffix>]
(see page 320)
:EXTernal:RANGe? (see
page 320)
<range> ::= vertical full-scale
range value in NR3 format
<suffix> ::= {V | mV}
:EXTernal:UNITs
<units> (see
page 321)
:EXTernal:UNITs? (see
page 321)
<units> ::= {VOLT | AMPere}
Table 13 :FUNCtion Commands Summary
Command Query Options and Query Returns
:FUNCtion:BUS:CLOCk
<source> (see
page 328)
:FUNCtion:BUS:CLOCk?
(see page 328)
<source> ::= {CHANnel<n> |
DIGital<d>}
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:FUNCtion:BUS:SLOPe
<slope> (see
page 329)
:FUNCtion:BUS:SLOPe?
(see page 329)
<slope> ::= {NEGative | POSitive
| EITHer}
:FUNCtion:BUS:YINCrem
ent <value> (see
page 330)
:FUNCtion:BUS:YINCrem
ent? (see page 330)
<value> ::= value per bus code,
in NR3 format
:FUNCtion:BUS:YORigin
<value> (see
page 331)
:FUNCtion:BUS:YORigin
? (see page 331)
<value> ::= value at bus code =
0, in NR3 format
