Agilent Technologies InfiniiVision 3000 X-Series Programmer's Guide

396 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
20 :MEASure Commands
:MEASure:DEFine
DELay, <delay spec>
(see page 413)
:MEASure:DEFine?
DELay (see page 414)
<delay spec> ::=
<edge_spec1>,<edge_spec2>
edge_spec1 ::=
[<slope>]<occurrence>
edge_spec2 ::=
[<slope>]<occurrence>
<slope> ::= {+ | -}
<occurrence> ::= integer
:MEASure:DEFine
THResholds,
<threshold spec> (see
page 413)
:MEASure:DEFine?
THResholds (see
page 414)
<threshold spec> ::= {STANdard} |
{<threshold mode>,<upper>,
<middle>,<lower>}
<threshold mode> ::= {PERCent |
ABSolute}
:MEASure:DELay
[<source1>]
[,<source2>] (see
page 416)
:MEASure:DELay?
[<source1>]
[,<source2>] (see
page 416)
<source1,2> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<return_value> ::=
floating-point number delay time
in seconds in NR3 format
:MEASure:DUAL:CHARge
[<interval>]
[,<source1>][,<source
2>] (see page 418)
:MEASure:DUAL:CHARge?
[<interval>]
[,<source1>][,<source
2>] (see page 418)
<interval> ::= {CYCLe | DISPlay}
<source1>,<source2> ::=
CHANnel<n> with N2820A probe
connected}
<n> ::= 1 to (# analog channels)
in NR1 format
<return_value> ::= area in
Amp-hours, NR3 format
:MEASure:DUAL:VAMPlit
ude
[<source1>][,<source2
>] (see page 419)
:MEASure:DUAL:VAMPlit
ude?
[<source1>][,<source2
>] (see page 419)
<source1>,<source2> ::=
CHANnel<n> with N2820A probe
connected
<n> ::= 1 to (# analog channels)
in NR1 format
<return_value> ::= the amplitude
of the selected waveform in volts
in NR3 format
Table 92 :MEASure Commands Summary (continued)
Command Query Options and Query Returns
