Agilent InfiniiVision 3000 X-Series Oscilloscopes
Programmer's Guide
20
:MEASure Commands
Select automatic measurements to be made and control time markers. See
"Introduction to :MEASure Commands" on page 406.
Table 92 :MEASure Commands Summary
Command Query Options and Query Returns
:MEASure:ALL (see
page 408)
n/a n/a
:MEASure:AREa
[<interval>][,][<sour
ce>] (see page 409)
:MEASure:AREa?
[<interval>][,][<sour
ce>] (see page 409)
<interval> ::= {CYCLe | DISPlay}
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<return_value> ::= area in
volt-seconds, NR3 format
:MEASure:BWIDth
[<source>] (see
page 410)
:MEASure:BWIDth?
[<source>] (see
page 410)
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<return_value> ::= burst width in
seconds, NR3 format
:MEASure:CLEar (see
page 411)
n/a n/a
:MEASure:COUNter
[<source>] (see
page 412)
:MEASure:COUNter?
[<source>] (see
page 412)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> | EXTernal} for MSO
models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<return_value> ::= counter
frequency in Hertz in NR3 format
