1 What's New
What's New in Version 2.30
New features in version 2.30 of the InfiniiVision 3000 X- Series oscilloscope
software are:
• Support for the N2820A high- sensitivity current probe.
• Saving Multi Channel Waveform data (*.h5) format files that can be
opened by the N8900A InfiniiView oscilloscope analysis software.
More detailed descriptions of the new and changed commands appear
below.
New Commands
Changed
Commands
Command Differences
:MEASure:DUAL:CHARge (see
page 418)
These are special measurements available with the N2820A
high sensitivity current probe when both the Primary and
Secondary probe cables are used.
These measurements join the Zoom In waveform data below
the probe's clamp level with Zoom Out waveform data above the
probe's clamp level to create the waveform on which the
measurement is made.
:MEASure:DUAL:VAMPlitude
(see page 419)
:MEASure:DUAL:VAVerage
(see page 420)
:MEASure:DUAL:VBASe (see
page 421)
:MEASure:DUAL:VPP (see
page 422)
:MEASure:DUAL:VRMS (see
page 423)
:SAVE:MULTi[:STARt] (see
page 617)
Lets you save Multi Channel Waveform data (*.h5) format files
that can be opened by the N8900A InfiniiView oscilloscope
analysis software.
:TRIGger:LEVel:ASETup (see
page 883)
Sets the trigger levels of all displayed analog channels to their
waveforms' 50% values.
Command Differences
:SAVE:WAVeform:FORMat
(see page 622)
The ALB format is no longer supported.
