Agilent Technologies InfiniiVision 3000 X-Series

What's New 1
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 45
Command Differences From 7000B Series Oscilloscopes
The Agilent InfiniiVision 3000 X- Series oscilloscopes command set is most
closely related to the InfiniiVision 7000B Series oscilloscopes (and the
7000A Series, 6000 Series, and 54620/54640 Series oscilloscopes before
them).
The main differences between the version 1.00 programming command set
for the InfiniiVision 3000 X- Series oscilloscopes and the 6.10 programming
command set for the InfiniiVision 7000B Series oscilloscopes are related
to:
• Built- in waveform generator (with Option WGN license).
• Built- in demo signals (with Option EDU license that comes with the
N6455A Education Kit).
• Reference waveforms (in place of trace memory).
• Multiple serial decode waveforms.
• Serial decode now available on 2- channel oscilloscopes.
• Enhanced set of trigger types.
• Additional measurements.
• Different path name format for internal and USB storage device
locations.
More detailed descriptions of the new, changed, obsolete, and discontinued
commands appear below.
New Commands
Command Description
:DEMO Commands (see
page 281)
Commands for using built-in demo signals (with the Option EDU
license that comes with the N6455A Education Kit).
:HARDcopy:NETWork
Commands (see page 357)
For accessing network printers.
:MEASure:AREA (see
page 409)
Measures the area between the waveform and the ground level.
:MEASure:BWIDth (see
page 410)
Measures the burst width from the first edge on screen to the
last.
:MEASure:NEDGes (see
page 427)
Counts the number of falling edges.
:MEASure:NPULses (see
page 428)
Counts the number of negative pulses.
:MEASure:PEDGes (see
page 432)
Counts the number of rising edges.
